| N599JH Weight & Balance | ||
|---|---|---|
| Station | Mass (lb) | CG (mm) |
| Empty Mass | 631 | 638 |
| Front Seat | -650 | |
| Front Ballast | -1840 | |
| Baggage | -650 | |
| Total | - | - |
Flight Parameters
| Loading | |
|---|---|
| Parameter | Value |
| Empty Weight | 631 lb |
| Max. Weight (w/ ballast) | 1003 lb |
| Max. Weight (no ballast) | 822 lb |
| Max. Load | 260 lb |
| Min. Front Seat Load (7kg nose ballast) | 130 lb |
| Max. Front Seat Load | 191 lb |
| Max. Cockpit Load | 191 lb |
| Max. Load Factor (@ VA) | 5.3 g (-2.6 g) |
| Max. Load Factor (@ VNE) | 4.0 g (-1.5 g) |
| Limiting Speeds | ||
|---|---|---|
| Parameter | Symbol | Value |
| Max. Aerotow Speed | VT | 92 kt |
| Max. Winch Speed | VW | 65 kt |
| Maneuvering Speed | VA | 92 kt |
| Rough Air Speed | VRA | 92 kt |
| Max. Landing Gear Speed | VLO | 92 kt |
| Never Exceed Speed | VNE | 119 kt |
| Performance Speeds @ 750 lb | |
|---|---|
| Parameter | Value |
| Stall | 34 kt |
| Stall (45 deg.) | 40 kt |
| Min. Sink (118 ft/min) | 43 kt |
| Best Glide (43:1) | 55 kt |
| Approach | 49 kt |
