Loading |
Parameter |
Value |
Empty Weight |
560 lb |
Max. Weight (dry) |
838 lb |
Max. Weight (wet) |
1157 lb |
Max. Wing Ballast |
441 lb |
Max. Cockpit Load |
300 lb |
Min. Front Seat Load |
154 lb |
Max. Front Seat Load |
243 lb |
Load Factor Limit (VA) |
5.3 g (-2.7 g) |
Load Factor Limit (VNE) |
4 g (-1.5 g) |
Limiting Speeds |
Parameter |
Symbol |
Value |
Max. Aerotow Speed |
VT |
97 kt |
Max. Winch Speed |
VW |
81 kt |
Maneuvering Speed |
VA |
108 kt |
Gusty Conditions Speed |
VB |
108 kt |
Never Exceed Speed |
VNE |
135 kt |
Performance Speeds @ 728 lb |
Parameter |
Value |
Stall |
30 kt |
Stall (45 deg.) |
36 kt |
Min. Sink (114 ft/min) |
43 kt |
Best Glide (45:1) |
51 kt |
Approach |
54 kt |
